Safety Cable silicone
Safety Cables silicone is a specialized silicone rubber formulated with excellent electrical insulation properties. It is designed specifically for applications that require insulation, protection, and sealing in electrical and electronic systems. This type of silicone rubber is commonly used in various industries where electrical insulation is critical for safety and performance.
Applications
-
1
Electrical connectors and insulators
-
2
Power distribution components
-
3
Cable accessories and insulation
-
4
Transformers and electrical motors
-
5
Insulating coatings for electronic components
-
6
High-voltage insulators and bushings
-
7
Switchgear and circuit breakers
Description
Special hot vulcanization silicone rubber insulator. Added curing agent.
- Electrical insulated molding type
- Excellent tracking resistance
- Formulated to meet UL94 V-0（thickness：2.0mm）
- Light gray appearance
- Pass RoHS
- Insulatators
- Composite insulators
| Type | Grade Name | Density g/cm3 | Hardness (Shore A) | Tensile Strength (Mpa) | Elongation at break % | Tear strength (KN/m) | Curing Condition |
| Safety Cables insulation | XHG-TY6861-60 | 1.50 | 58 | 4.0 | 220 | 12 | 40% active DBPH, 1%; press cure: 10min/170℃ |
| XHG-TY6861-70 | 1.55 | 67 | 4.0 | 220 | 10.0 | ||
| XHG-TY6961-60 | 1.48 | 62 | 5.0 | 300 | 13.5 |
